Key Features
- RCBO Combination: Integrates both Miniature Circuit Breaker (overload & short-circuit) and RCCB (30 mA AC residual current protection) in a single module
- Poles & Voltage: Single-phase + Neutral (1P+N), suitable for 230–240 V AC circuits
- Current Rating: 10 A, with C‑curve tripping for inductive loads like motors and lighting k.
- Leakage Sensitivity: 30 mA residual current trip ensures protection against earth leakage and electric shock.
- Breaking Capacity: Up to 6 kA, making it robust for domestic and light industrial systems
- Standards: Compliant with IEC 61009‑1, widely certified for safety
Design & Installation
- DIN-rail Mountable: Compact footprint ideal for residential panels.
- C-curve Characteristic: Allows brief inrush currents (e.g., motor start-up) without nuisance tripping.
- Reliable Construction: Rated for 10,000 mechanical operations; fully modular for easy replacement
Typical Applications
- Perfect for home circuits with appliances prone to leakage—bathrooms, kitchens, EV chargers, workshops.
- Suitable for industrial light‑duty circuits with protected load control.
