REGULATEUR DE TENSION 3KVA-G TND1(SVC)-3
106,750 CFA
The CHINT TND1(SVC)-3 is a 3 kVA single-phase automatic servo‑controlled voltage regulator (actuated by servomotor/brush mechanism) that stabilizes fluctuating inputs (approximately 160–250 VAC) to a regulated 220 VAC ±4% output, features full protections (over‑voltage, under‑voltage, overload, short‑circuit), low waveform distortion (< 2%), compact and lightweight design (~12.5 kg)
Key Technical Characteristics
- Series / Model: CHINT TND1(SVC)-3 (TND1 family, 3 kVA single-phase)
- Input & Output Voltage: Designed for input range 160–250 VAC, outputs 220 VAC ±4%, responds within ≤6 s to ±20 V changes in input
- Operation Mechanism: Utilizes a servo motor driving a brush/rocker-arm for fine voltage adjustment; ensures low distortion output (less than 2%)
- Physical Data: Weighs ~12.5 kg; dimensions approx. 245 × 305 × 240 mm, cooling via natural convection (“AN” type)
- Protection & Features: Includes comprehensive protections—overload, short-circuit, thermal shutdown, input/output over/under‑voltage; efficient and reliable operation with low internal power loss
- Typical Applications: Best suited for household appliances, medical equipment, offices, labs or light industrial usage in areas with unstable mains voltage
| Weight | 12,5 kg |
|---|---|
| Dimensions | 245 × 305 × 240 cm |
