U‑1000 4×25 mm² RM (semi‑rigid)
10,500 CFA
Product Description
The Borsan U‑1000 4×25 mm² RM semi‑rigid cable is a 0.6/1 kV low‑voltage, four‑core power cable, with the following characteristics:
The Borsan U‑1000 4×25 mm² RM semi‑rigid cable is a 0.6/1 kV low‑voltage, four‑core power cable, with the following characteristics:
- Copper conductors, Class 2 stranded, each 25 mm² — semi‑rigid to enhance handling and minimize deformation ..
- XLPE insulation, delivering strong thermal and electrical performance for long-term reliability .
- PVC filler and outer sheath, black, flame-retardant (IEC 60332‑1), with good UV, chemical and weather resistance ..
- Conductor DC resistance: approximately 0.727 Ω/km at 20 °C ..
- Approximate outer diameter: 23.92 mm .
- Net weight: ~1,314.8 kg per km .
- Current-carrying capacity: about 133 A in air, 145 A in ground.
- Bending radius: ≥12 × outer diameter (~287 mm) .
- Operating temperatures: continuous use up to 90 °C, installation above 5 °C; short‑circuit can reach 250 °C; ambient range −25 … +60 °C .
- Voltage withstand: tested at 4 kVAC, rated for 0.6/1 kV service .
- Standards: conforms to XP C 32‑321 / NF C 32‑321 and IEC 60332‑1 flame-retardant test
Key Specifications Summary
FeatureSpecificationConductors4 × 25 mm² Cu, Class 2 stranded, semi‑rigidInsulationXLPEFiller & SheathPVC, flame‑retardant, UV & weather resistantRated Voltage0.6/1 kV (tested to 4 kVAC)DC Resistance~0.727 Ω/km @20 °COuter Diameter23.92 mmWeight~1,314.8 kg/kmCurrent Capacity133 A (air), 145 A (ground)Bending Radius≥12×D (~287 mm)Temp Range−25 … +60 °C ambient; 90 °C continuous; 250 °C short‑circuitStandardsXP C 32‑321 / IEC 60332‑1
