:Core Characteristics
- Conductors: Four stranded copper cores, 6 mm² each (Class 2).
- Insulation: XLPE; Filler & Sheath: PVC, black outer sheath .
- Voltage Ratings: 600/1000 V nominal, 4 kV test.
- Temperature Range: –25 °C to +90 °C during operation; withstands up to 250 °C during short-circuit events .
- Bending Radius: ≥ 12 × outer diameter .
- Current Capacity: ~52 A in air, ~64 A when buried
- Outer Diameter/Weight: ≈ 16 mm diameter; ~390 kg/km
- Standards & Safety: Compliant with IEC 60502‑1/NF C 32‑321, flame retardant to IEC 60332‑1; UV-resistant (AN3) for use without external protection
